Dell Precision 5820 Workstation

Built For Your Future

Your Precision 5820 Tower grows with your ideas no matter where they take you, thanks to a new chassis that combines a versatile design with outstanding storage scalability.

Operating System

With Windows 10 Pro for Workstations or Ubuntu 18.04 LTS – for a smooth, versatile PC experience.

Blazing fast performance

Brainpower that matches yours: The latest Intel® Xeon® processor powers your most demanding applications. Now featuring a new generation of single-socket architecture with up to 18 cores, you can extract maximum performance for your biggest ideas.
Accelerate every project: Run your software as fast as possible and get real-time results thanks to this memory expandable machine with up to 512GB of 2666MHz RDIMM ECC memory (not available with Core X CPUs).
Drown out distraction: Focus on your tasks with the workstation that’s quieter than ever. A new multichannel thermal design delivers advanced cooling and acoustics.

Built for your future

Room for more: Your Precision 5820 Tower grows with your ideas no matter where they take you, thanks to a new chassis that combines a versatile design with outstanding storage scalability.
Adapts to your innovations: Your Precision 5820 Tower is ready for complex projects, including virtual reality and AI workflows, with the next generation AMD Radeon Pro™ and highest-performing NVIDIA^® Quadro^® RTX graphics. Your workstation supports up to 600W of graphics up to 300W per card (950W PSU required).
No project is too big: Up to six 2.5″ or five 3.5″ drives and front access storage including SATA, SAS (not available on systems with Core X CPUs) and PCIe M.2/U.2 NVMe SSD can be configured for up to 68TB total storage and easily swapped. With the hot-swap feature on the M.2 and U.2 PCIe NVMe SSDs, you can remove drives without shutting down the workstation.

Intelligence that matches yours

Dell Optimizer for Precision is a built-in AI platform that learns how you work and continuously adapts to your style to create a smarter, more personalized and productive experience.
ExpressResponse: Launch your most used apps faster. We use built-in AI and Intel^® Adaptix™ Technology to adjust performance levels where you need them most.

Reliability where it matters most

Stay safe, stay secure: Reduce downtime with Dell Reliable Memory Technology (RMT) Pro. Designed to work with ECC memory, RMT protects your machine from potential crashes by mapping out bad memory locations after the system reboots.
Reliably access your data: Improve the availability of your data with hardware and software optional RAID storage options including PCIe NVMe SSDs and optional Smart Card (CAC/PIV) readers that let you determine who can access your system.
Your work can count on it: Precision Workstations are tested to ensure the high-performance applications you rely on every day run smoothly. Dell ISV-certifications cover the most popular independent software applications.

Al-ready Data Science Workstations

Intelligently designed for Data Scientists. The latest Precision Data Science Workstations utilize Al to empower users to get their most important work done faster by fine-tuning their devices for optimized performance of the applications they use the most.

Manage and secure with ease

Ultimate convenience

Manage all of your Windows 10 endpoints from one console with Dell Client Command Suite and VMware^® Workspace ONE™ integration.

Comprehensive threat prevention

With SafeGuard and Response, you have the tools and security experts to protect your ecosystem from cyber threats, giving you the freedom and peace of mind to focus on other strategic initiatives.

Remotely manage

Dell unique vPro extensions can remotely manage and run diagnostics on a fleet of devices, whether they are powered on or off.

We’ve got your business covered

ProDeploy Client Suite: We help you deploy PCs with greater speed, less effort and more control. You will direct every detail of your deployment with our TechDirect portal that features an unprecedented level of control, automation and simplicity.
ProSupport: Let us make hardware and software support easy. ProSupport offers 24×7 access to local language, advanced technology experts who contact you when critical issues arise. We do all this so you can focus on the strategic work that drives your business forward.
ProSupport Plus: With our most complete support service for PCs, you get all the capabilities of ProSupport plus hard drive failure prevention, repair for drops, spills and surges and hard drive retention in the case of replacement. In today’s fast moving culture, there’s no time for downtime. Dell has your back. Upgrade to ProSupport Plus.

WANT TO REQUEST THIS PRODUCT? CLICK HERE

Customize Spec

Processor

Intel Xeon Processor W-2225 (4C, 4.1GHz 4.6GHz Turbo HT 8.25MB (105W)) DDR4-2933
Intel Xeon Processor W-2235 (6C, 3.8GHz 4.6GHz Turbo HT 8.25MB (130W)) DDR4-2933
Intel Xeon Processor W-2245 (8C, 3.9GHz 4.7GHz Turbo HT 16.5MB, (155W)) DDR4-2933
Intel Xeon Processor W-2255 (10C, 3.7GHz 4.7GHz Turbo HT 19.25MB 165W DDR4-2933
Intel Xeon Processor W-2265 (12C, 3.5GHz 4.8GHz Turbo HT 19.25MB (165W)) DDR4-2933
Intel Xeon Processor W-2275 (14C, 3.3GHz,4.8GHz, Turbo, HT, 19.25M, (165W)) DDR4-2933
Intel Xeon Processor W-2295 (18C, 3.0GHz 4.6GHz Turbo HT 24.75MB (165W)) DDR4-2933

Chassis Options

Precision 5820 Tower 425W Chassis CL
Precision 5820 Tower 950W Chassis CL

Graphics Card

1. AMD Single

AMD Radeon Pro WX 3200, 4GB, 4 mDP (FWS)
AMD Radeon Pro W5500, 8GB, 4 DP (Precision 7920R/7920T/7820T/5820T)
AMD Radeon Pro W5700, 8GB, 5 mDP, USB-C (Precision 7920R/7920T/7820T/5820T)

2. nVIDIA Single

NVIDIA Quadro P2200, 5GB, 4 DP
Nvidia Quadro RTX4000, 8GB, 3DP, VirtualLink (XX20T)
Nvidia Quadro RTX5000, 16GB, 4DP, VirtualLink (XX20T)
Nvidia Quadro RTX6000, 24GB, 4DP, VirtualLink (XX20T)
Nvidia Quadro RTX 8000, 48GB, 4DP, VirtualLink (xx20)
Nvidia RTX A6000, 48GB, 4DP (xx20T)

3. AMD Dual

Dual AMD Radeon Pro WX 3200, 4GB, 4 mDP (FWS)
Dual Radeon Pro WX 5100, 8GB, 4 DP (5820T)
Dual AMD Radeon Pro W5500, 8GB, 4 DP (Precision 7920R/7920T/7820T/5820T)
Dual AMD Radeon Pro W5700, 8GB, 5 mDP, USB-C (Precision 7920R/7920T/7820T/5820T)

4. nVIDIA Dual

Dual NVIDIA Quadro P2200, 5GB, 4 DP
Dual Nvidia Quadro RTX4000, 8GB, 3DP, VirtualLink (XX20T)
Dual Nvidia Quadro RTX5000, 16GB, 4DP, VirtualLink (XX20T)
Dual NVLink Nvidia Quadro RTX5000, 16GB, 4DP, VirtualLink (5820T/7820T)
Dual Nvidia Quadro RTX6000, 24GB, 4DP, VirtualLink (XX20T)
Dual NVLink Nvidia Quadro RTX6000, 24GB, 4DP, VirtualLink (5820T/7820T)
Dual NVLink Nvidia Quadro RTX8000, 48GB, 4DP, VirtualLink (5820T/7820T)

Memory

8GB (1x8GB) DDR4 2933MHz RDIMM ECC Memory
32GB (2x16GB) DDR4 2933MHz RDIMM ECC Memory
32GB (4x8GB) DDR4 2933MHz RDIMM ECC Memory
64GB (4x16GB) DDR4 2933MHz RDIMM ECC Memory
64GB (8x8GB) DDR4 2933MHz RDIMM ECC Memory
128GB (2x64GB) DDR4 2933 RDIM ECC Memory
128GB (4x32GB) DDR4 2933MHz RDIMM ECC
128GB (8x16GB) DDR4 2933MHz RDIMM ECC Memory
192GB (6x32GB) DDR4 2933MHz RDIMM ECC Memory
256GB (4x64GB) DDR4 2933MHz RDIMM ECC Memory
256GB (8x32GB) DDR4 2933MHz RDIMM ECC Memory
512GB (8x64GB) DDR4 2933 RDIM ECC Memory

Hard Drive

1. 2.5″ SATA Enterprise SSD

2.5 1.92TB SATA AG Enterprise Solid State Drive

2. 3.5″ SATA HDD

3.5″ 2TB 7200rpm SATA AG-Enterprise Hard Drive

3. Class 20 SATA SSD

2.5″ 256GB SATA Class 20 Solid State Drive
2.5″ 512GB SATA Class 20 Solid State Drive

4. SAS HDD

2.5″ 300GB 15K SAS 12Gbps AG-Enterprise Hard Drive
2.5″ 600GB 15K SAS 12Gbps AG-Enterprise Hard Drive
2.5″ 2.4TB 10K SAS 12Gbps AG-Enterprise Hard Drive
3.5″ 4TB 7200rpm Nearline SAS AG-Enterprise Hard Drive

5. Class 40 PCIE SSD

M.2 256GB PCIe NVMe Class 40 Solid State Drive
M.2 512GB PCIe NVMe Class 40 Solid State Drive
M.2 1TB PCIe NVMe Class 40 Solid State Drive
M.2 2TB PCIe NVMe Class 40 Solid State Drive

6. Class 50 PCIE SSD

M.2 512GB PCIe NVMe Class 50 Solid State Drive
M.2 1TB PCIe NVMe Class 50 Solid State Drive

7. SED

M.2 512GB PCIe NVMe Class 40 SED (OPAL 2.0) Solid State Drive
M.2 1TB PCIe NVMe SED (OPAL 2.0) Class 40 Solid State Drive

Wireless

Intel® Dual Band Wireless AC 8265 (802.11ac) 2×2 + Bluetooth module

Network Cards

No Add-In Network Card (Integrated NIC only)

Ports & Slots

1. Power button/Power light

2. Drive activity light

3. SD card slot

4. USB 3.1 Gen 1 ports

5. USB 3.1 Gen 1 Type-C port with PowerShare

6. USB 3.1 Gen 1 Type-C port

7. Headset port

8. 5.25 inch bay (optional)

9. Optical drive

10. Drive access release latch

11. Drive carriers

12. Microphone/Line-in port

13. PS/2 Mouse port

14. USB 3.1 Gen 1 ports

15. Discrete graphics card slot (optional)

16. Padlock ring

17. Security cable slot

18. Power cable connector

19. Line-out port

20. Serial port

21. PS/2 Keyboard port

22. Network port

23. USB 3.1 Gen 1 port (supports smart Power-On)

24. Expansion card slots

Dimensions & Weight

1. Height: 16.45” (417.9 mm)

2. Width: 6.94” (176.5 mm)

3. Depth: 20.4” (518.3 mm)

4. Starting weight: 32 lb (15.9kg)
